Winter is already over in the Laurentians, and for a few weeks now ski
conditions are so horribles that it's not fun anymore and I'm sick of applying
and cleaning klister on my skis. We will soon have rain and mud and flooding
everywhere. April is definitely the worst month in Quebec despite sunny and
longer days. But the good thing is that I suddenly have a huge amount of time
left for other things. Like system administration and coding.
Thus I picked up a task from my todo list that I always wanted to do: trying
molecule over our Ansible roles and playbook at FACiL. The infrastructure
running behind the Services FACiLes project is setup
and maintained 100% with Ansible. All our roles and playbooks are public and
hosted on Gitlab.
molecule is a Python tool
developed by the same team as Ansible and aims running different kind of tests
over your ansible roles: linting, role execution on multiple targets and
scenarios, ensure idempotence over multiple executions and running unit
tests on the target.
I am not going to write a full tutorial on molecule, a lot of them already
exist on Internet, though not always up to date since molecule is still a
young project and in heavy development. The official
documentation is a bit rough to
get started and to understand the scope of molecule. A good
I found for being the most up to date and accurate.
Instead, in this post I'm going to explain how I use it to test our roles, with
some tips I didn't find in the official documentation. I also played with
Gitlab CI so molecule tests are run on each git push, but it will be for
We start by creating a molecule directory in our role:
$ molecule init scenario --verifier-name goss --driver-name docker --role-name <role>
It will create a directory named molecule/ in your role's directory. You can
have multiple scenarios for your role, stored under molecule/ directory. By
molecule init will create the scenario default:
$ tree molecule/
│ └── test_default.yml
Each file above are just here to help you to get started and can be edited as you
want. Options we passed to the
molecule init command are just here to alter
these files. I usually prefer copying the molecule/ directory from an
existing role (which is totally acceptable) since I have done some extra
customization on it.
molecule.yml is the only molecule configuration file. Here is the
molecule.yml we use in our roles :
- name: molecule-monitoring-tools
molecule is designed to be very extensible. For instance, it uses the
galaxy dependency resolver (dependencies are defined in the meta/main.yml
file of your role) and ansible as a provisioner (this is the only one
supported for now but we can imagine molecule will be able to use other
configuration management tools).
yamllint as the linter for all YAML file of the role (including
molecule's own files!) and
ansible-lint for ansible files.
For some reasons, we don't want to run some Ansible tasks when testing the
role. molecule let us pass any
ansible-playbook option with the dict
provisioner:options. Here we excluded tasks which have the
molecule-converge-notest tag on them.
And finally we tell molecule to run the role in a Docker container. molecule
supports a large range of drivers, including LXC containers, Vagrant VMs and
common public cloud providers. Even if we use LXC containers on production, I
choose to use the Docker driver with molecule because, first it's more easy to
setup on a personal machine, and second because this is the only supported
option if we want to run molecule tests on Gitlab's shared runners (using
Docker in Docker), I will talk about it later in a second post.
Most of our roles don't work inside a minimal Docker container, so we use
geerlingguy/docker-debian9-ansible Docker image. The image provides a more
complete Debian system (with systemd and common tools). It is maintained by
Jeff Geerling, who wrote a lot of Ansible roles and uses it to test his own roles.
By default, molecule spawns a container named instance. It's a bad idea since
I ended up with conflicts when I tried to launch tests on multiple roles at the
same time, each of them was executed in the same container. Thus I edited
platforms:name key so that it bears the role's name.
This file is only here if you want to build your Docker container on each test.
You can use any Docker image (defined in platforms:image) and this Dockerfile
will install requirements such as python, sudo, bash and ca-certificates
package to run Ansible.
Since the image we use already contains those dependencies, we instruct
molecule not to build another Docker image (platforms:pre_build_image).
this way, we also speed up tests.
INSTALL.rst is an informal file containing instructions to others
contributors and requirements to run molecule tests. For instance, we need to
have the Docker engine and docker-py installed on our machine.
After molecule.yml, this is the second most important file. Once molecule has spawned the container, it will run this playbook.
Here is its content:
- name: Converge
- role: <role>
Pretty simple, it applies onto the spun up container. But if your role requires some variables to be set, or dependencies that aren't declared in your role's meta/main.yml file, you can add them here. For instance:
- name: Converge
- role: <other role>
- role: <role>
verify.yml and tests/test_default.yml
Finally, those two files are for unit tests. verify.yml installs Goss (the verifier tool) in the container and run tests it finds in the tests/ directory. Although it's a very interesting subject, I didn't dig too much into unit tests for now.
First, to enable bash completion:
$ eval "$(_MOLECULE_COMPLETE=source molecule)"
molecule without argument will show you the list of available sub-commands. I'm not going to explain all of them, and I don't even sure what all these sub-commands do, I still learning about molecule.
Run linting tools on your role:
$ molecule lint
Test your role into a freshly created container (by executing playbook.yml on it):
$ molecule converge
molecule converge will automatically lint your code prior to run it.
At this time you can either login to the container to manually check what has been done:
$ molecule login
molecule converge if you obtained errors and have fixed them in your role.
molecule converge allows us to pass almost any
ansible-playbook option. For instance, you may want to debug tasks with a specific tag:
$ molecule converge -- -vvv --tags <tag>
To destroy the running container so you can start with a new one:
$ molecule destroy
If you just want to start a container but don't execute anything in it (for instance if you want to known the state of a file in a brand new install):
$ molecule prepare
To run idempotence check (molecule will simply run the playbook.yml a second time and check that no tasks report a changed state):
$ molecule idempotence
All these previous commands are useful while you are developing a role. Once you have done or did only minors edits (you are pretty confident that you didn't break anything), it's handy to run all the test suite at once:
$ molecule test
It will lint your code, start a new container, apply playbook.yml, verify idempotence, run unit tests and finally destroy the container.
